Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate

Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate
Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate

Large Image :  Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate

Product Details:
Place of Origin: Japan
Brand Name: BENENV
Certification: SW17Q10910R0S
Model Number: KDS-1212
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Export Plywood Case
Delivery Time: 6~8 weeks
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 30 Sets per month

Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate

Description
Product Name: Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate Capacity: 1-280 DS-kg/hr
Weight: 600 Kg Power: 1.5 KW
Material: SUS304 Or SUS316 Motor Brand: SEW Or NISSEI Or Sumitomo
Electrical Components Brand: Schneider, Omron, Siemens Warranty: 2 Years
Application: Activated Sludge Dewatering, Especially For Oily Sludge
High Light:

sludge dewatering press

,

sludge belt filter press

Product Introduction of KDS Sludge Thickening Machine

KDS Sludge Thickening Machine is a revolutionaly new sludge thickening press of the news technology from Japan. BENENV focus on integrating the best resources worldwide since the day it is founded. Thus we are also one step forward of the market.
KDS sludge thickening machine is of large throughput, self-cleaning function by slits opposite continuos rotation, no vibration and noise, and very low power consumption. Besides, the structure is very simple, thus the operation and maintenance is easy.
Its brand new thickening technology enables automatically self-cleaning for the filter gap during sludge thickening and thickening. So this machine has stable and constant throughput without need of backwash water to prevent clog. This self-cleaning mechanism enables KDS sludge thickening machine to be an effective machine for oily and grease sludge.

Working Principle
Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate 0


Sludge Thickening And Dewatering Machine Advantages

No Clog and backwash
Solid-liquid seperation and self-cleaning function are carried out simultaneously by oval discs rotation between filtrate gap

Stable Treatment capacity
Continuos cleaning process avoids throughput reduction which could easily occur in other dewatering equipments

Large Throughput
Smooth rotation of oval discs enables large transportload

Easy Maintenance
Due to the simple strcuture, the maintenance is easy


Thickener Model

Model DN Oval Discs Column Numbers Capacity m³/h Sludge (reference) kg-DS/h Power Weight
      1.0 mm 1.0 mm 3.8Ф380V
SS-312 300 mm 12 23 49 0.2 kW 1/160 110 kg
SS-412 400 mm 12 30 67 0.2 kW 1/160 200 kg
SS-512 500 mm 12 38 83 0.2 kW 1/160 210 kg
SS-612 600 mm 12 45 100 0.4 kW 1/160 230 kg
SS-712 700 mm 12 74 160 0.4 kW 1/160 380 kg
SS-812 800 mm 12 86 185 0.75 kW 1/160 410 kg
SS-912 900 mm 12 98 210 0.75 kW 1/160 440 kg
SS-1012 1000 mm 12 107 230 0.75 kW 1/160 470 kg
SS-1212 1200 mm 12 130 280 1.5 kW 1/160 600 kg


Applications
· Food wastes treatment in school feeding center for scraps of food processing;
· Fishery wastes treatment;
· Crusher drainage waste disposer;
· Process before treatment wastewater;
· Drain water off devise from food etc;
· Primary filtration for wastes coming from grease traps;
· Enrichment screen before dehydration;
· Dehydrator;

Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate 1



Solid-liquid separation for oil waste etc;

Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate 2



Primary treatment for wastes produced from livestock etc.

Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate 3



Crushed wastes collection such as plastic etc.





Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate 4



Construction sites where sludge is treated by dewatering equipment screw press sludge image is before and after treatment.

Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate 5



Purification of lakes and rivers
. Primary treatment
. Sediment and sludge treatment



Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate 6



Application Fields

Large Throughput Multi Disc Sludge Dewatering Machine Easy To Operate 7

FAQ
Q: Are You Trading Company Or Manufacture?
A: We Are Both Manufacture And Trading Company. We Have Over 30 Years' Professional Experience As a Waste Water Treatment Equipment Manufacturer And Engineering Service Enterprise.

Q : What Are Your Main Products?
A:Keywords :Sludge Dewatering Machine Equipment, Screw Type Sludge Dewatering Press Sludge Screw Press, Dewatering Sludge Machine Screw Press ,Sewage Treatment Equipment ,Sludge Treatment Plant,Screw Press Sludge Dewatering ,Dewatering Sludge,Dewatering Machine For Sludge, Dewatering Sludge Machine Screw Press, Rotary Drum Bar Screens, Equipment DAF, DAF Price ,Dissolved Air Flotation System Price, Sludge Shaftless Screw Conveyor,Chemical Dosing Device ,MBBR Price,MBBR Media,Disc Diffuser, Polymer Preparation Chemical Dosing System,

Q: How Can I Find The Suitable Model?
A: Please Provide Flow Rate, Solids Content And Sludge Type, We Can Assist You In Model Selection.

Q: Where Is Your Factory Located?
A: Yixing City, We are in the famous city of environmental protection equipment ,professional for Sludge screw press dewatering Machine ,Which is Very Close To Shanghai With Only Less Than 3 Hours' Driving. Welcome for your visiting.

Q: Do You Provide OEM Service?
A: Yes. We Can Do The Customized Design According To Your Different Request for sludge Dewatering.

Q: How About The Production Capacity Of Your Company?
A: Our Factory Covers Area Over 22,000M2 And Produces Machines 2000 Sets Per Year.

Q: How Could We Trust You And Your Company? Is This First Time Transaction?
A: A: Our Company Has More Than 30 Years Professional Experience. We Cooperate Over 1000 Customers.In China And Overseas. We Export Nearly 60 Countries All Over The World.And We Have More Than 60+Patents, CE,ISO 9001,SGS Certificates. And We Have Company In Japan,Great Technology And Great Quality.

Q: Do You Offer After-Sales Service?
A: Video Technical Support, Online Support,Spare Parts,Field Maintenance Repair Service

Q: How Long is Your Warranty?
A: 2 Years After The Arrival Of The Goods. During This Period, As Long As It Is Not a Man-Made Damage, We Send The Damaged Parts Free Of Charge.

Q: What About Your Produce Time?What Kind Of Transportation Do You Offer?
A:Within 30 Days Against Down Payment. Air, Land & Sea .

Q: What Kind Of Payment Do You Accept?
A: T/T, L/C, Paypal, Cash, D/P, D/A, Western Union, Money Gram.

Sludge Dewatering Press,Sludge Dewatering Machine,Screw Press.
