Home ProductsWastewater Treatment Machine

Automatic Wastewater Treatment Machine With Durable Stainless Steel Grille

Certification
China Benenv Co., Ltd certification
China Benenv Co., Ltd certification
I'm Online Chat Now

Automatic Wastewater Treatment Machine With Durable Stainless Steel Grille

Automatic Wastewater Treatment Machine With Durable Stainless Steel Grille
Automatic Wastewater Treatment Machine With Durable Stainless Steel Grille Automatic Wastewater Treatment Machine With Durable Stainless Steel Grille

Large Image :  Automatic Wastewater Treatment Machine With Durable Stainless Steel Grille

Product Details:
Place of Origin: China
Brand Name: BENENV
Certification: SW17Q10910R0S
Model Number: MDS202
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiatable
Packaging Details: Export polywood
Delivery Time: 3-7 weeks
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 99 Sets per 6 weeks

Automatic Wastewater Treatment Machine With Durable Stainless Steel Grille

Description
Brand Origin: Japan Operation: 2 Years
Electrical Components: Schneider, Omron Service Life: Automatic
Warranty: >15 Years After-sales Service Provided: Engineers Available To Service Machinery Overseas
Function: Waste Water Treatment Machine Color: According Customers Demands
High Light:

sewage treatment machine

,

sludge press machine

,

SS Grille Wastewater Treatment Machine

Automatic Wastewater Treatment Machine Stainless Steel Grille Machine


sewage treatment Grille cleaning machine to treat domestic wastewater is mainly composed of a frame, a drive device, a gear ring and a transmission chain. The enamel teeth made of ABS engineering plastics, nylon 6, nylon 1010, or stainless steel are assembled in a certain order on the gingival shaft to from a closed rake tooth chain. Underwater girds (carious teeth) trap dirt along the track. When reaching the head. due to the guiding action of the curved rails and gears, so that relative motion between adjacent caries occurs, push the dirt out, unloading into the dirt container. At the same time, the special rotary brush removes a small amount of residual dirt from the caries.



Model
power(kw)
liquid flow rate(m/s)
depth(m)
Rake tooth pitch(mm)
TLGX-300
0.37-0.75
0.8
1.0
100/150
TLGX-500
0.37-0.75
0.8
1.0
100/150
TLGX-800
0.37-0.75
0.8
1.0
100/150
TLGX-1000
1.1-2.2
0.8
1.0
100/150
TLGX-1200
1.1-2.2
0.8
1.0
100/150
TLGX-1500
1.1-2.2
0.8
1.0
100/150



Product Display

Automatic Wastewater Treatment Machine With Durable Stainless Steel Grille 1



Model Selection

Model
WAS Sludge
& Chemical Precipitated Sludge
(Thin Sludge)

Dissolved Air Flotation Sludge
Mixed Raw Sludge
Aerobic Digested Sludge
& Sewage Sludge
Sludge Concentration (TS)

0.2%

1%

2%

5%

3%
MDS 051
~0.4 kg-DS/hr
(0.2 m³/hr)
~0.6 kg-DS/hr
(0.06 m³/hr)
~2 kg-DS/hr
(0.1 m³/hr)
~4 kg-DS/hr
(0.08 m³/hr)
~5 kg-DS/hr
(0.16 m³/hr)
MDS 101
~2 kg-DS/hr
(1.0 m³/hr)
~3 kg-DS/hr
(0.3 m³/hr)
~5 kg-DS/hr
(0.25 m³/hr)
~10 kg-DS/hr
(0.2 m³/hr)
~13 kg-DS/hr
(0.43 m³/hr)
MDS 131
~4 kg-DS/hr
(2.0 m³/hr)
~6 kg-DS/hr
(0.6 m³/hr)
~10 kg-DS/hr
(0.5 m³/hr)
~20 kg-DS/hr
(0.4 m³/hr)
~26 kg-DS/hr
(0.87 m³/hr)
MDS 132
~8 kg-DS/hr
(4.0 m³/hr)
~12 kg-DS/hr
(1.2 m³/hr)
~20 kg-DS/hr
(1.0 m³/hr)
~40 kg-DS/hr
(0.8 m³/hr)
~52 kg-DS/hr
(1.73 m³/hr)
MDS 202
~16 kg-DS/hr
(8.0 m³/hr)
~24 kg-DS/hr
(2.4 m³/hr)
~40 kg-DS/hr
(2.0 m³/hr)
~80 kg-DS/hr
(1.6 m³/hr)
~104 kg-DS/hr
(3.47 m³/hr)
MDS 311
~20 kg-DS/hr
(10 m³/hr)
~30 kg-DS/hr
(3.0 m³/hr)
~50 kg-DS/hr
(2.5 m³/hr)
~100 kg-DS/hr
(2.0 m³/hr)
~130 kg-DS/hr
(4.33 m³/hr)
MDS 312
~40 kg-DS/hr
(20 m³/hr)
~60 kg-DS/hr
(6.0 m³/hr)
~100 kg-DS/hr
(5.0 m³/hr)
~200 kg-DS/hr
(4.0 m³/hr)
~260 kg-DS/hr
(8.67 m³/hr)
MDS 313
~60 kg-DS/hr
(30 m³/hr)
~90 kg-DS/hr
(9.0 m³/hr)
~150 kg-DS/hr
(7.5 m³/hr)
~300 kg-DS/hr
(6.0 m³/hr)
~390 kg-DS/hr
(13 m³/hr)
MDS 412
~80 kg-DS/hr
(40 m³/hr)
~120 kg-DS/hr
(12 m³/hr)
~200 kg-DS/hr
(10 m³/hr)
~400 kg-DS/hr
(8.0 m³/hr)
~520 kg-DS/hr
(17.3 m³/hr)
MDS 413
~120 kg-DS/hr
(60 m³/hr)
~180 kg-DS/hr
(18 m³/hr)
~300 kg-DS/hr
(15 m³/hr)
~600 kg-DS/hr
(12 m³/hr)
~780 kg-DS/hr
(26 m³/hr)



The product function



In sewage treatment projects, whether large sewage treatment plants or small integrated sewage treatment equipment will be used in the first equipment is grid.Grille is installed in the most front end of sewage treatment project generally, the function is tointercept large suspended or floating objects, to ensure that the follow-up secondary biochemical treatment can work normally.

Cooperation Case

Application in Various Industry



Grilles are used on many work platforms, or at water outlets, corridors, etc.Besides, sewage treatment plant grille can be widely used in chemical industry, paper industry, power plant, sewage treatment plant, food processing plant, smelting plant, mine, salt farm,nuclear power plant, battery plant,etc.Can be used as pedestrian walkways, bridge plate, industrial floor, operating platform, trench cover plate, tray, guardrail, fence, shelves, isolation belt, green corridors, floor walk step granary slope, the tank top, power plant water treatment workshop, drain cover plate, shaft cover plate, sewage treatment plant, wash the steam room glass fiber reinforced plastic plate, car washing drainage board, ski resorts, FRP FRP stand sidewalks, fence, along the metro lines FRP plank road maintenance, yacht dock, landscape bridge deck, FRP cable branch, found, municipal construction, afforestation trees FRP gratings, lawn, factory operation platform, isolation belt, lawn isolation belt, boat deck, etc.

Camparison between Sludge Thickening and Dewatering Machine and the other equipments



Automatic Wastewater Treatment Machine With Durable Stainless Steel Grille 2

Company Information


Jiangsu Benenv Environmental Protection Technology Co., Ltd. is an environmental protection company, specialized in mechanisms, environmental engineering and other related science. With research center in Japan, we have factory and office in China. Benenv specializes in the design, engineering, supply and installation of domestic and commercial water, waste water and sewage treatment systems, gas pollution control, and other environmental engineering products. Our company possesses complete sets of process design, equipment supply, constructions, and technology innovation. Overall, we are highly qualified in delivering turnkey and BOT projects for any industry. We have abundant experience in the treatment of industrial, domestic and commercial hazard wastewater. Benenv is staffed with local and overseas professionals with more than 15 years of acquired technical expertise and experience, offering various technologies and allied services. Our company works closely with the top 10 universities and scientific institutes to keep our cutting-edge technology and transform science and technology into productivity. Our company also works with the government, and is authorized as the liaison office of Yixing government to perform technology cooperation with foreign countries.

Packaging and Delivery

1. Waterproof packing with the international export standard by 20ft, 40ft, 40hp container. Equipment Fittings, Electric Motor and Power Cabinet will be packed in Wooden Case or Iron Box. Other Equipment will be packed by Color-Stripes Plastic Cloth.

2. The whole plant machinery size are large as normal, so we will use Waterproof cloth to pack all of them. The motor, gear box or other easily damaged parts, we will put them into box. We have a professional shipping department, they will try their best to save your container quantity.



FAQ

Q: Are You Trading Company Or Manufacture?
A: We Are Both Manufacture And Trading Company. We Have Over 30 Years' Professional Experience As a Waste Water Treatment Equipment Manufacturer And Engineering Service Enterprise.

Q : What Are Your Main Products?
A:Keywords :Sludge Dewatering Machine Equipment, Screw Type Sludge Dewatering Press Sludge Screw Press, Dewatering Sludge Machine Screw Press ,Sewage Treatment Equipment ,Sludge Treatment Plant,Screw Press Sludge Dewatering ,Dewatering Sludge,Dewatering Machine For Sludge, Dewatering Sludge Machine Screw Press, Rotary Drum Bar Screens, Equipment DAF, DAF Price ,Dissolved Air Flotation System Price, Sludge Shaftless Screw Conveyor,Chemical Dosing Device ,MBBR Price,MBBR Media,Disc Diffuser, Polymer Preparation Chemical Dosing System,

Q: How Can I Find The Suitable Model?
A: Please Provide Flow Rate, Solids Content And Sludge Type, We Can Assist You In Model Selection.

Q: Where Is Your Factory Located?
A: Yixing City, We are in the famous city of environmental protection equipment ,professional for Sludge screw press dewatering Machine ,Which Is Very Close To Shanghai With Only Less Than 3 Hours' Driving. Welcome for your visiting.

Q: Do You Provide OEM Service?
A: Yes. We Can Do The Customized Design According To Your Different Request for sludge Dewatering.

Q: How About The Production Capacity Of Your Company?
A: Our Factory Covers Area Over 22,000M2 And Produces Machines 2000 Sets Per Year.

Q: How Could We Trust You And Your Company? Is This Your First Time Transaction?
A: A: Our Company Has More Than 30 Years Professional Experience. We Cooperate Over 1000 Customers.In China And Overseas. We Export Nearly 60 Countries All Over The World.And We Have More Than 60+Patents, CE,ISO 9001,SGS Certificates. And We Have Company In Japan , Great Technology And Great Quality.

Q: Do You Offer After-Sales Service?
A: Video Technical Support, Online Support,Spare Parts,Field Maintenance Repair Service

Q: How Long is Your Warranty?
A: 2 Years After The Arrival Of The Goods. During This Period, As Long As It Is Not a Man-Made Damage, We Send The Damaged Parts Free Of Charge.

Q: What About Your Produce Time?What Kind Of Transportation Do You Offer?
A:Within 30 Days Against Down Payment. Air, Land & Sea .

Q: What Kind Of Payment Do You Accept?
A: T/T, L/C, Paypal, Cash, D/P, D/A, Western Union, Money Gram
