Product Details:
Place of Origin: China
Brand Name: BENENV
Certification: SW17Q10910R0S
Model Number: MDS202
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiatable
Packaging Details: Export polywood
Delivery Time: 3-7 weeks
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 99 Sets per 6 weeks

Cattle Manure Wastewater Treatment Machine CE Certificate Easy Maintenance

Description
Brand Origin: Japan Operation: 2 Years
Motor: Sumitomo, Nissei Service Life: Automatic
Application: Activated Sludge Dewatering, Especially For Oily Sludge Certificate: ISO 9000, CE Certificate
After-sales Service Provided: Engineers Available To Service Machinery Overseas Material: Steel
Power: Depend On The Treating Volume Product Name: Screw Sludge Dewatering Machine
High Light:

sewage treatment machine

,

sludge press machine

,

Cattle Manure Wastewater Treatment Machine

CE Certificate Wastewater Treatment Machine Cattle Manure Dewatering Press


Cattle Manure Dewatering Press with CE Certificate and Japanese Standard

KDS Cattle Manure Dewatering Press is a revolutionaly new manure dewatering press of the newest technology from Japan. BENENV focus on integrating the best resources worldwide since the day it is founded. Thus we are also one step forward of the market.


KDS cattle manure dewatering press is of large throughput, self-cleaning function by slits opposite continuos rotation, no vibration and noise, and very low power consumption. Besides, the structure is very simple, thus the operation and maintenance is easy.

Its brand new dewatering technology enables automatically self-cleaning for the filter gap during manure dewatering . So this machine has stable and constant throughput without need of backwash water to prevent clog. This self-cleaning mechanism enables KDS manure dewatering press to be an effective machine for oily and grease manure.

SPECIFICATIONS FOR SS-311D Sludge Thickening Machine
Dry Solid Capacity
20-30 kg-DS/h
Flow Capacity
1.3-2.0 m3/h
Gap Size
1 mm
Power
0.4 kw
Material
SS 304
Net Weight
120 kg
PLC
Schneider
Product Display




Main Features

1) No Clog and backwash
Solid-liquid separation and self-cleaning function are carried out simultaneously by oval discs rotation between filtrate gap

2) Stable Treatment capacity
Continuous cleaning process avoids throughput reduction which could easily occur in other thickening equipment

3) Large Throughput
Smooth rotation of oval discs enables large transport load

4) Easy Maintenance
Due to the simple strcuture, the maintenance is easy



Model Selection

Model
WAS Sludge
& Chemical Precipitated Sludge
(Thin Sludge)

Dissolved Air Flotation Sludge
Mixed Raw Sludge
Aerobic Digested Sludge
& Sewage Sludge
Sludge Concentration (TS)

0.2%

1%

2%

5%

3%
MDS 051
~0.4 kg-DS/hr
(0.2 m³/hr)
~0.6 kg-DS/hr
(0.06 m³/hr)
~2 kg-DS/hr
(0.1 m³/hr)
~4 kg-DS/hr
(0.08 m³/hr)
~5 kg-DS/hr
(0.16 m³/hr)
MDS 101
~2 kg-DS/hr
(1.0 m³/hr)
~3 kg-DS/hr
(0.3 m³/hr)
~5 kg-DS/hr
(0.25 m³/hr)
~10 kg-DS/hr
(0.2 m³/hr)
~13 kg-DS/hr
(0.43 m³/hr)
MDS 131
~4 kg-DS/hr
(2.0 m³/hr)
~6 kg-DS/hr
(0.6 m³/hr)
~10 kg-DS/hr
(0.5 m³/hr)
~20 kg-DS/hr
(0.4 m³/hr)
~26 kg-DS/hr
(0.87 m³/hr)
MDS 132
~8 kg-DS/hr
(4.0 m³/hr)
~12 kg-DS/hr
(1.2 m³/hr)
~20 kg-DS/hr
(1.0 m³/hr)
~40 kg-DS/hr
(0.8 m³/hr)
~52 kg-DS/hr
(1.73 m³/hr)
MDS 202
~16 kg-DS/hr
(8.0 m³/hr)
~24 kg-DS/hr
(2.4 m³/hr)
~40 kg-DS/hr
(2.0 m³/hr)
~80 kg-DS/hr
(1.6 m³/hr)
~104 kg-DS/hr
(3.47 m³/hr)
MDS 311
~20 kg-DS/hr
(10 m³/hr)
~30 kg-DS/hr
(3.0 m³/hr)
~50 kg-DS/hr
(2.5 m³/hr)
~100 kg-DS/hr
(2.0 m³/hr)
~130 kg-DS/hr
(4.33 m³/hr)
MDS 312
~40 kg-DS/hr
(20 m³/hr)
~60 kg-DS/hr
(6.0 m³/hr)
~100 kg-DS/hr
(5.0 m³/hr)
~200 kg-DS/hr
(4.0 m³/hr)
~260 kg-DS/hr
(8.67 m³/hr)
MDS 313
~60 kg-DS/hr
(30 m³/hr)
~90 kg-DS/hr
(9.0 m³/hr)
~150 kg-DS/hr
(7.5 m³/hr)
~300 kg-DS/hr
(6.0 m³/hr)
~390 kg-DS/hr
(13 m³/hr)
MDS 412
~80 kg-DS/hr
(40 m³/hr)
~120 kg-DS/hr
(12 m³/hr)
~200 kg-DS/hr
(10 m³/hr)
~400 kg-DS/hr
(8.0 m³/hr)
~520 kg-DS/hr
(17.3 m³/hr)
MDS 413
~120 kg-DS/hr
(60 m³/hr)
~180 kg-DS/hr
(18 m³/hr)
~300 kg-DS/hr
(15 m³/hr)
~600 kg-DS/hr
(12 m³/hr)
~780 kg-DS/hr
(26 m³/hr)



Dewater Principle

    After gravity concentration in the concentrating section, the sludge is transported to the dewatering section. During the process of advancement, as the filter gap and pitch gradually decrease, and the blocking effect of the back pressure plate, internal pressure is generated, and the volume is continuously reduced to reach sufficient Purpose of dehydration.

1.The main body of the dewatering machine is a filtering device formed by the fixed ring and the swimming ring being laminated on each other, and the spiral shaft penetrating therethrough. The front section is the concentration section, and the rear section is the dewatering section.

2. The filter gap formed between the fixed ring and the swimming ring and the pitch of the screw shaft gradually become smaller from the concentrated part to the dewatered part.

3. While the rotation of the screw shaft pushes the sludge from the thickening section to the dewatering section, it also continuously drives the swimming ring to clean the filter gap to prevent clogging.

4. After the gravity concentration in the concentration part, the sludge is transported to the dewatering part. During the process of advancement, as the filter slit and pitch gradually become smaller, and the blocking effect of the back pressure plate generates a great internal pressure and volume Constantly shrink to achieve the purpose of full dehydration.




Cooperation Case

Application in Various Industry



The screw type sludge dewatering machine is suitable for municipal wastewater treatment, petroleum, chemical, tobacco, leather, paper, textile, printing and dyeing, chemical fiber, food, brewing, slaughtering, breeding and other industries. It has the characteristics of low energy consumption, low noise, small floor space, unattended operation, continuous work, etc.

Recently, the belt fiter press is widely used in the sludge dehydrating, however, some problems are being with this machine, such as the large quantities of water consumption, operation requirement is high etc. But the screw type sludge dehydrator is a new type sludge dehydrator. With its advantages, such as energy saving, operaton stable, highly automation it is quickly recognized and accepted by the market.



Exclusive pre-concentration design, applicable for sludge of concentration from 2000mg/L to 50000mg/L. Besides, Due to the innovation of the structure design, it is highly suitable to oil sludge
