Moving Bed Biological Reactor Biological Membrane Mbbr Media biofilm carrier

Certification
China Benenv Co., Ltd certification
China Benenv Co., Ltd certification
I'm Online Chat Now

Moving Bed Biological Reactor Biological Membrane Mbbr Media biofilm carrier

Moving Bed Biological Reactor Biological Membrane Mbbr Media biofilm carrier
Moving Bed Biological Reactor Biological Membrane Mbbr Media biofilm carrier Moving Bed Biological Reactor Biological Membrane Mbbr Media biofilm carrier Moving Bed Biological Reactor Biological Membrane Mbbr Media biofilm carrier

Large Image :  Moving Bed Biological Reactor Biological Membrane Mbbr Media biofilm carrier

Product Details:
Place of Origin: Japan
Brand Name: BENENV
Certification: SW17Q10910R0S
Model Number: BNPE Φ25×10
Payment & Shipping Terms:
Minimum Order Quantity: 1 Cubic Meter
Price: Negotiable
Packaging Details: Standard packing
Delivery Time: 2-4 weeks
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 1000 Cubic Meter/Cubic Meters per Month

Moving Bed Biological Reactor Biological Membrane Mbbr Media biofilm carrier

Description
Product Name: Moving Bed Biological Reactor Biological Membrane Mbbr Media Biofilm Carrier Application: Waste Water Treatment
Size: Φ215 Sample: Available
Materials: ABS Or UPVC Or PP Warranty: 2 Years
Service Life: >5 Years
High Light:

moving bed biological reactor

,

mbbr biofilm carriers

Moving Bed Biological Reactor Biological Membrane Mbbr Media Biofilm Carrier



Introduction of Mbbr Media




MBBR is a moving media system, used in Integrated Fixed-lm Activated Sludge (IFAS) and moving bed biofilm reaction (MBBR) system.

The wastewater goes through suspending media of MBBR reactor, forming biological membrane on the surface of media gradually. With the action of microbial on the biological membrane, wastewater is purified. MBBR biofilm carrier can move freely in the reactor with the mixing of the water. For the aerobic reactor, the aeration will make the media move; for the anaerobic reactor, mechanic mixing will make the media move. Our MBBR biofilm carrier is new-developed media, has better treatment effect compared with traditional media.



Moving Bed Biological Reactor Biological Membrane Mbbr Media biofilm carrier 0



Process Principal:




The waste water go through the suspending media of MBBR reactor, form the biological membrane on the surface of the media gradually, with the action of the microbial on the biological membrane, the waste water is purified. The media can move freely in the reactor with the mixing of the water; For the aerobic reactor, the aeration will make the media move; For the anaerobic reactor, mechanic mixing will make the media move. Our MBBR media is new-developed media for the MBBR process, has better treatment effect compare to traditional media.



Parameters of Mbbr Media



echnical specification of MBBR biofilm carrier:



Model Specification B1-10-7.5 B3-25-10 B5-25-8
Diameter×Height (mm) Φ10×7.5 Φ25×10 Φ25×8
Density (g/cm3) 0.96-0.99 0.96-0.99 0.96-0.99
Mean thickness (mm) 0.40 0.35-0.40 0.30-0.35
Weight (kg/m3) 150-160 100-110 110-120
Surface area (m2/m3) ≥750 ≥600 ≥750
Dosing ratio (%) 10-50 15-65 10-60
Material HDPE HDPE HDPE
Service life (year) ≥20 ≥20 ≥20



MBBR Media Features:



1. Easy to operate and control



2. Proven performance for BOD, Ammonia, and Total Nitrogen removal



3. Small footprint - often half the size of traditional activated sludge systems



4. Highly adaptable to wide variety of new or existing tank configurations



5. Allows for future expansion without additional construction by just adding media



6. Adaptable to variable flows and loads



7. Nitrification in cold weather



8. Prevents washout of nitrifiers by retaining biomass on the media



9. Perfect for plant retrofits and expansions



10.No maintenance, stainless steel aeration grids



Application




MBBR biofilm carrier can be used in both aerobic process and anaerobic process.



MBBR is a cost-effective solution for existing activated sludge plants that need more advanced treatment. Because little or no additional tankage is required, it is an ideal solution for plants with limited space for expansion. It is also an excellent choice for space efficient, high performance new plant designs.



Moving Bed Biological Reactor Biological Membrane Mbbr Media biofilm carrier 1



Packing and Delivery


PACKAGE: Standard export packing Wooden Packing
DELIVERY TIME: 25--35 working days once receipt the payment



Moving Bed Biological Reactor Biological Membrane Mbbr Media biofilm carrier 2

FAQ
Q: Are You Trading Company Or Manufacture?
A: We Are Both Manufacture And Trading Company. We Have Over 30 Years' Professional Experience As a Waste Water Treatment Equipment Manufacturer And Engineering Service Enterprise.

Q : What Are Your Main Products?
A:Keywords :Sludge Dewatering Machine Equipment, Screw Type Sludge Dewatering Press Sludge Screw Press, Dewatering Sludge Machine Screw Press ,Sewage Treatment Equipment ,Sludge Treatment Plant,Screw Press Sludge Dewatering ,Dewatering Sludge,Dewatering Machine For Sludge, Dewatering Sludge Machine Screw Press, Rotary Drum Bar Screens, Equipment DAF, DAF Price ,Dissolved Air Flotation System Price, Sludge Shaftless Screw Conveyor,Chemical Dosing Device ,MBBR Price,MBBR Media,Disc Diffuser, Polymer Preparation Chemical Dosing System.

Q: How Can I Find The Suitable Model?
A: Please Provide Flow Rate, Solids Content And Sludge Type, We Can Assist You In Model Selection.

Q: Where Is Your Factory Located?
A: Yixing City, We are in the famous city of environmental protection equipment ,professional for Sludge screw press dewatering Machine ,Which is Very Close To Shanghai With Only Less Than 3 Hours' Driving. Welcome for your visiting.

Q: Do You Provide OEM Service?
A: Yes. We Can Do The Customized Design According To Your Different Request for sludge Dewatering.

Q: How About The Production Capacity Of Your Company?
A: Our Factory Covers Area Over 22,000M2 And Produces Machines 2000 Sets Per Year.

Q: How Could We Trust You And Your Company? Is This First Time Transaction?
A: A: Our Company Has More Than 30 Years Professional Experience. We Cooperate Over 1000 Customers.In China And Overseas. We Export Nearly 60 Countries All Over The World.And We Have More Than 60+Patents, CE,ISO 9001,SGS Certificates. And We Have Company In Japan,Great Technology And Great Quality.

Q: Do You Offer After-Sales Service?
A: Video Technical Support, Online Support,Spare Parts,Field Maintenance Repair Service.

Q: How Long is Your Warranty?
A: 2 Years After The Arrival Of The Goods. During This Period, As Long As It Is Not a Man-Made Damage, We Send The Damaged Parts Free Of Charge.

Q: What About Your Produce Time?What Kind Of Transportation Do You Offer?
A:Within 30 Days Against Down Payment. Air, Land & Sea .

Q: What Kind Of Payment Do You Accept?
A: T/T, L/C, Paypal, Cash, D/P, D/A, Western Union, Money Gram.

K1 MBBR Bio Filter Media;Mbbr Filter Media;Mbbr Bio Filter Media Carrier
