High Quality Compact Wastewater Treatment System Membrane Bioreator Municipal
1. The integrated sewage treatment equipment is buried below the surface, and the surface above the equipment can be used as greening or other land, without the need for building houses, heating and heat preservation.
2. The secondary biological contact oxidation treatment process adopts pushed-flow biological contact oxidation, and the treatment effect is better than the fully mixed biological contact oxidation tank or the two-stage series fully mixed biological contact oxidation tank. Compared with the activated sludge tank, it has a smaller volume, stronger adaptability to water quality, better impact load resistance, stable effluent water quality and no sludge expansion. The new type of elastic stereoscopic packing is used in the tank, with large specific surface area, easy to hang the membrane of microorganisms, and demembrane. Under the same organic load condition, the removal rate of organic compounds is high, which can improve the solubility of oxygen in the air in water.
3. The biological contact oxidation method is adopted in the biochemical tank. The volume load of the filler is relatively low.
4. The deodorization method of the buried domestic sewage treatment equipment includes conventional high-altitude exhaust and soil deodorization measures.
5. The whole equipment processing system is equipped with fully automatic electrical control system and equipment fault alarm system, which runs reliably. Usually, it does not need special personnel to manage, but only needs timely maintenance of the equipment.
||Reference outside size(L*W*H) mm
Several usage methods of integrated sewage treatment equipment:
1. Be able to treat the comprehensive wastewater of living system and its similar organic wastewater;
2. It is made of glass fiber reinforced plastic and stainless steel, with excellent properties of corrosion resistance and anti-aging, and its service life is over 50 years;
3. The whole set of equipment is simple in construction and easy in operation. All the mechanical equipment is controlled by automation.
Buried sewage treatment technology has a variety of, under the premise of water standards, the outstanding advantages are:
1. The equipment is buried under the surface, which can be afforested and the environment is beautiful.
2. Generally, the whole equipment does not need special personnel to manage.
3. The floor space can be reduced. Parking lots and other facilities can be built above the equipment.
4. No impact on the surrounding environment, low sludge production, noise less than the standard of the second class area.
5. Simple operation, new technology, good effect and long service life.
6. The equipment can be arranged according to the standard or special arrangement according to the terrain.
All pipes of the sewage treatment integration equipment are PVC pipes or stainless steel pipes, and the connections between pipes are bonded with PVC binder or welded with stainless steel. The packing USES the suspension type biological packing as the biological carrier, the biomass is big, hangs the film easily, does not knot the ball, does not block.
Installation and maintenance:
1. Foundation: If WSZ series equipment is placed above the floor, only a concrete floor with the same shape as the equipment needs to be prepared as the foundation. The foundation pressure must be greater than 4T/m2, and it should be horizontal and smooth. If the equipment is buried below the floor, the elevation of the foundation shall be less than or equal to the elevation of the equipment and no water is allowed to accumulate in rain.
2, Installation: According to the installation diagram in place, each box in place in turn, the position and direction of the box should not be put wrong, spacing each other should be accurate, and connected to the pipeline. Fill the equipment with clean water and check whether there is any leakage in the pipes. If there is no leakage, cover the box with soil until the equipment checks the holes and level the ground. Connect the control line of the electric control box to the water pump, connect the electric control box to the power supply, pay attention to the fan, motor steering, and the direction indicated by the fan.
Application of integrated sewage treatment equipment:
1. Hotels, restaurants and nursing homes;
2. Residential communities, villages and market towns;
3. Station, expressway service area, harbor wharf and ship;
4. Factories, mines, troops, tourist spots and scenic spots;
5. Industrial organic wastewater similar to domestic sewage, such as food industry.
Packing and Delivery
1. The normal package is wooden box(Size: L*W*H). If export to European countries,the wooden box will be fumigated.If container is too tighter,we will use pe film for packing or pack it according to customers special request.
2. We also support 20',40' container delivery, use soft packaging to protect machine well. If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
